The Revolution MVP Rotary Wheel Blow Molding Systems

A key Graham Engineering innovation at the heart of the Revolution MVP is the Modular Clamp Station. Each clamp station is independent of the others, and all forces are self-contained within the clamp. Water manifolds through the platens and the individual clamps are removable for offline maintenance to reduce downtime. This modularity enables the number of clamp stations to vary from 12 to 24 based on your needs. That also allows variations in configuration based on application and bottle height.

The variable pitch innovation creates a multiplier effect enabling 100 possible positions, with each clamp station adjustable in 1 inch increments, from 39 inches to 47 inches. This not only enables a range of bottle sizes up to 16” in height to be run on a single platform, but also provides flash optimization at each bottle height, particularly important for multilayer applications. Once again, we engineer with your time in mind, it takes about 5 minutes per clamp station to vary the pitch in a simple process. Simply loosen bolts on each side of the clamp, adjust the radius inward or outward, and then reset the pin and retighten the bolts.
